Dufour 500 Grand Large

General Information

A long distance, performance cruiser, fully kitted out to travel oceans, this Dufour 500GL benefits from having Raymarine Radar, AIS, VHF, 2x MFDs and Autopilot. Both Bow & Stern Thrusters, generator, reverse cycle air conditioning and a Dishwasher.

Construction

Hull is hand-laminated in polyester/glass fibre; sides made from vacuum-bonded PVC foam core sandwich.
Decoration is Grey
Gelcoat is NPG gelcoat with first mat impregnated with NPG resin forming an optimum barrier against osmosis.
Structure has a hull bottom counter-moulded, floors laminated into the hull.
Deck Sandwich with injected PVC foam core
Ballast the Keel bolts bear on stainless back-plates
Rudder is Semi-elliptical shape, filled with closed-cell epoxy foam.
Rudder stock: Solid stainless steel.
Non-slip deck surface

Deck & Fittings

• Handrails: Solid wood handrails on coach roof.
• Fixed toe rails: solid wood
• Anchor locker: Self-draining with built-in windlass support and anchor chain eyebolt, lockable hatch cover.
• Anchor roller: Single retractable anchor roller
• Bow pulpits: Stainless, opening for easy access and for spinnaker handling
• Stern pulpits: Jack staff bracket, navigation light, and opening lifelines with hook.
• Stanchions: With 2 rows of life-lines.
• Solid wooden toe-rail.
• Shroud chain plates: Chain plates on hull sides
• Safety chain plates: Safety harness chain plates in cockpit floor
• Miscellaneous chain plates: 2 backstay chain plates
• Midships mooring cleats: 2, aluminium
• Mooring cleat: 4, aluminium.
• Rubbing strips: 6 stainless, on hull shearline
• Fuel deck fillers: 2
• Water deck fillers: 3
• Mainsheet tracks: On coach roof with adjusting car.
• Genoa tracks: 2 genoa sheet tracks, plunger-adjustable low-lead cars
• Downhaul
• Through-deck fitting: Stainless swan-neck for electrical and electronic cables
• Deck organizers: 2 deck 4-sheave organizers for halyard, sheet, and reef line returns.
• Halyard winches: 2 halyard winches on coach roof.
• Sheet winches: 2 genoa sheet winches at helm positions
• Jamcleats: 2 rows of jamcleats port / starboard level with the companionway
• Furler line jamcleats: 1 at aft end of side deck
• Hatch covers: Sliding companionway hatch in Plexiglas

Cockpit

• Cockpit bench seats: Teak covered.
• Helmsman’s seat: Teak covered.
• Lockers: 1 large side locker to Stbd with strut-assisted closing and fixing for padlock.
• Helm: Wheel diameter 900 mm
• Helm console: Polyester.
• Engine controls: At starboard helm position
• Compasses: 2 on columns
• Instrumentation: Port and Stbd helm positions
• Gas locker: Under port helmsman’s seat
• Stern door: Opens in centre by swinging up
• BIB locker: Under floor, Stbd helm position
• Tender locker: Under floor, port helm position
• Handrail: Stainless, on cockpit table
• Shower: In aft central section
• Shore supply: Stbd helm position
• Bathing ladder: Foldaway stainless bathing ladder.
• Cockpit floor: Non-slip polyester floor
• Emergency tiller: A stainless tiller with deck plate for access

Rigging and Sails

Mast is Anodized aluminium with 2 levels of swept spreaders
• Rigging: 9/10 fractional
• Mast stepping: On deck
• Lights: Anchor and steaming lights.
• Topping lift: Boom topping lift cleats.
• Boom: Anodized aluminium fitted with 2 continuous reefers.
• Roller-furler: Genoa roller furler.
• Standing rigging: Continuous in stainless single-strand cable, chrome-plated bronze rigging screws, comprising: forestay, backstay bridle with twin rigging screws, inter and lower shrouds.
• Backstay: double
• Running rigging: “Running rigging in pre-stretched textile including: main and genoa halyards, boom topping lift, main and genoa sheets, 2 continuous reef lines, leech tensioner, 2 mainsheet car adjustments, furling line, downhaul tackle.
• Mainsail: 2 wide reef strips, with battens and bag
Genoa: Furling genoa with UV-protection

Interior

Woodwork: Real wood veneer in Moabi, solid Moabi
• Floors: Moabi laminate.
• Doors: Fitted with twin-bolt anti-vibration locks, cabin doors can be blocked in the open position
• Mattresses: Mattresses are in quilted, antiallergic fabric.
• Cushions: Saloon cushions and cabin mattresses fitted with removable covers.
• Head-liner: Lined with wood.
• Version 4 cabin 2 shower/1 head

Lighting

• Hull: 8 hull ports
• Coachroof, fixed: 5 fixed ports
• Coachroof, opening: 3 opening ports with curtains
• Hatches: 9 deck hatches
• Indirect lighting: Under ceiling
• Lighting: Numerous spots and reading lights.
• Courtesy light: Low-level lighting around saloon furniture

Galley

• Configurations: Lateral
• Worktop: ‘Corian®’ synthetic resin with wooden fiddle.
• Sink: Stainless twin-bowl sink in stbd module
• Water: Hot and cold pumped water with brushed stainless single-lever mixer tap.
• Gas cooker: 3-burner gas cooker with oven and grill, on gimbals, with stainless hand rail in port module
• Crockery storage: Dowels to retain crockery when heeling.
• Refrigerators: 12 V refrigerator Storage bins. Separation bulkhead
• Port module
• Refrigerator access: Front access to refrigerator. Via the worktop for the cool-box
• Storage: 5 cubby-holes to port and 4 cubby-holes to stbd, under floor.
• 220 V microwave oven: In stbd hull cubby-hole
• Pump: Sea-water pump built-in under floor to stbd
• Waste bin: Sort compartments, to stbd

Fwd Cabin

• Berth: 200 × 160 cm approx.
• Mattress: 10 cm thick foam mattress with washable cover.
• Stowage: Below berth.
• Cubby-hole along side of hull.
- 2 hanging lockers with shelves.
- Below berth.
- 2 tidy pockets
• Water tank: Below berth
• Access: To navigation instrument transducers

Aft Cabins

Berth: 200 × 165 cm approx.
• Mattress: 10 cm thick foam mattress with washable cover.
• Fuel tank: Under port and stbd berths
• Water tank
• Stowage: Hanging locker with shelves Cubby-holes along side of hull.
• Soundproofing: Double bulkhead provides acoustic and thermal insulation from adjoining engine compartment.
• Technical area: Between aft berths
